HAND LOWERING CONTROL- 3 POSITIONS
Lifting - neutral - lowering. Foot pedal is an added feature. Neutral allows
free handle movement when the truck is in motion. The handle returns automatically
to the vertical position.
HIGH QUALITY HYDRAULIC UNIT
The hydraulic system is the result of years of research and development, including
a load limiter that prevents premature wear resulting from overloading. A special
design of lowering valve permits gentle lowering of heavy loads. No moisture can
get into the unit and it is leak proof.
QUALITY FEATURES
- Safety designed loop handle, includes neutral position, and fingertip release
- Spring-a-matic handle self returns to vertical position
- 2150 pivot action maneuvers in compact area
- One piece formed steel “c" channel tapered, reinforced forks
- Leak-proof pump assures maintenance-free
- Hard chrome-plated ram and piston
- Urethane seals and wipers
- Large steer wheels with “ball-thrust” steering
- Sealed ball bearings throughout
- All pivot points can be lubricated easily
- Tapered fork ends and nylon rollers permit easy entry and exit of pallets
- Polyurethane steer wheels and steel load rollers
- Only 1 snap ring and 4 pins to remove the hydraulic unit
- Powder coated quality safety color after anti-rust treatment
|
Load capacity
|
|
4,400 lbs.
|
|
|
Lowered height of forks
|
|
2"
|
|
|
Raised height
|
|
5.75"
|
|
|
Overall width across forks (A)
|
|
27"
|
|
|
Fork width
|
|
6.3"
|
|
|
Space between forks (B)
|
|
14.4"
|
|
|
Standard fork length (L)
|
|
48"
|
|
|
Load rollers - steel
|
|
2" x 3.7"
|
|
|
Front wheels (steer) - polyurethane
|
|
6" x 1.9"
|
|
|
Body length (including pump)
|
|
14"
|
|
|
Load roller axle to fork-tip end of truck:
|
|
|
Roller down
|
|
7.83"
|
|
|
Roller up
|
|
9.84"
|
|
|
Approximate weight
|
|
180 lbs. |
|
