The quick lift requires only two pump strokes to lift the pallet.
…compared to the standard 6 pump strokes needed by most hand pallet trucks
- increasing both the speed and efficiency of pallet loading and moving.
This unique pallet truck has a quick lift pump system that is really useful when
quick pallet movements are important. The first pump stroke raises the forks straight
to the underside of the pallet, and the second lifts it clear of the ground. This
is much quicker than the 6 or more strokes required by normal pallet trucks.
When loads exceed 700 lbs up to a maximum of 5500 lbs. the pump unit in the pallet
truck senses this and automatically reverts to normal pump mode for ease of use.
Quality Features
- Quick-lift pump. The forks reach the pallet on the first pump stroke and lift ft
on the second
- Automatically switches over to normal lift when the load exceeds about 330 lbs
- High capacity – 5,500 lbs
- Perfectly ergonomic designed handle offers an excellent and comfortable grip in
all situations and temperatures
- 220 turning angle gives an outstanding maneuverability even in the tightest spaces,
such as inside trailers
- Low weight makes the pallet truck very handy to use
- Quick and easy-change cassette valve houses the entire hydraulic control system
and safety valve
- Made of stainless steel and can be replaced in a few minutes
- Self-lubricating bearings, for preventing damage and assuring longer life
- Hard chrome plate pistons and double seals ensure a tight and stable hydraulic system
- Special valve makes lowering quickly without load, slower with heavy load
- Overload relief valve - safety - prevents damage to equipment
- 12 grease fittings - for long durability and quiet operation
- Re-enforced forks
- 7.9” steering wheels - for smooth and easy operation
- Available with polyurethane, rubber or nylon wheels
- Available with entry rollers for easy entry into pallets with bottom stringers
|
Load capacity
|
|
5,500 lbs.
|
|
|
Lowered height
|
|
2.9"
|
|
|
Raised height
|
|
7.2"
|
|
|
Overall fork width
|
|
27"
|
|
|
Fork width
|
|
6.3"
|
|
|
Fork length
|
|
48"
|
|
|
Wheels
|
|
polyurethane
|
|
|
Turning radius
|
|
220°
|
|
|
Weight
|
|
155 lbs. |
|
