Easy as 1-2-3-4 to operate
End "operator acrobatics" - two feet on the floor at all times
- Lift - lift load with short pumping strokes
- Lower - lower with light pressure on fingertip control
- Neutral- position
- Brake - safety spring loaded loop handle allows load to be lowered while in motion
to act as a brake
Quality Features
- Leak-proof pump with overload capacity assures maintenance-free service
- Hard chrome plated ram & piston
- Sealed ball bearings throughout
- Urethane seals and wipers
- One piece formed steel "c" channel tapered, reinforced fork
- Large steer wheels with "ball-thrust" steering
- Full adjustable push rods on forks
- 2000 pivot action maneuvers in compact areas
- Only 3 bolts to remove hydraulic unit
- Spring-a-matic handle self returns to vertical position
- Tapered fork ends and nylon rollers permit easy entry and exit of pallets
- Self-lubricating bearings at all pivot points: no greasing required
|
Load capacity
|
|
5500 lbs,
|
|
Lowered height of forks
|
|
2.9"
|
|
Raised height
|
|
7¾"
|
|
Overall width across forks
|
|
20 ½" or
27"
|
|
Fork width
|
|
6½"
|
|
Standard fork lengths
|
|
32"-36"-42"-48"
|
|
Special widths & lengths available upon request Load roller
|
|
2.9"x3.6" |
|
Front wheel (steer)
|
|
7"x2"
|
|
Body length (including pump)
|
|
14"
|
|
Load roller axle to fork tip end of truck:
|
|
|
Roller down
|
|
4½"
|
|
Roller up
|
|
7½"
|
|
Wheels
|
|
poly/nylon
|
|
Optional polyurethane, nylon or steel
|
|
|
Approximate weight
|
|
170 lbs.
|
