HAND LOWERING CONTROL-3 POSITIONS
Lifting - neutral - lowering. Foot pedal is an added feature. Neutral allows
pumping at the most convenient angle to the operator and free handle movement when
the truck is in motion. The handle returns automatically to the vertical position.
BRAKE
Brake safety spring-loaded loop handle allows load to be lowered while in motion
to act as a brake.
PROVEN RELIABILITY
- Hard chrome-plated ram & piston
- Self-lubricating bearings at all pivot points
- Large steer wheels with "ball-thrust" steering
- High tensile steel frame and seamless forks
- Grease fittings
- Full adjustable push rods on forks
- 2300 pivot action maneuvers in compact areas
- Spring-a-matic handle self returns to vertical position
- Only 1 snap ring - 4 pins to remove hydraulic unit
- Nylon steer wheels & load rollers standard, for easy quiet travel
- Tapered fork ends and maintenance-free skids for easy entry and exit of pallets
- Powder coated quality safety color after anti-rust treatment
- Safety designed loop handle, includes neutral position, and fingertip release
|
Load capacity
|
|
5,500 lbs.
|
|
|
Lowered height of forks
|
|
2.9"
|
|
|
Raised height
|
|
7 ¾"
|
|
|
Overall width across forks (A)
|
|
20 1/2" - 27"
|
|
|
Fork width
|
|
6"
|
|
|
Space between forks (B)
|
|
8.5" or 15"
|
|
|
Standard fork length (L)
|
|
36" - 42" - 48"
|
|
|
Load rollers - nylon
|
|
2.9" x 3 5/8"
|
|
|
Front wheels (steer) - nylon
|
|
7" x 2"
|
|
|
Wheels
|
|
Nylon
|
|
|
Body length (including pump)
|
|
16"
|
|
|
Load roller axle to fork-tip end of truck:
|
|
|
Roller down
|
|
6 ¾"
|
|
|
Roller up
|
|
9 ¾"
|
|
|
Approximate weight
|
|
190 lbs. |
